Sit Stand Desk | 180x80 cm | White with black frame

503-35 4B172 180-80S3 WM
503-35 4B172 180-80S3 WM
Sit Stand Desk | 180x80 cm | White with black frame
Sit Stand Desk | 180x80 cm | White with black frame
Sit Stand Desk | 180x80 cm | White with black frame
Sit Stand Desk | 180x80 cm | White with black frame
Sit Stand Desk | 180x80 cm | White with black frame
$ 1119 incl. GST
Item no.: 503-35 4B172 180-80S3 WM

This height-adjustable desk pairs a symmetrical foot and top arm design with reliable everyday performance for a 1800 x 800 mm tabletop. The included 35 mm chrome base ring enables the complete 620-1270 mm stroke and can be removed to lower the minimum height for shorter users. With a 100 kg load capacity, an 37 min assembly time, and a choice of white with an melamine surface, it is suited to both home and professional workspaces.

A two-arrow user panel comes fitted as standard. The control system uses a simple switching principle that is both robust and reliable. Raised tactile arrows help users identify the controls by touch. The desk comes with a cable tray mounted under the tabletop to maintain a clean look, using a smart hinged design for quick opening right under the cable grommet exit point. Mobile castors are attached to the legs, making it easy to roll the desk whenever needed. The layout is RAL 9004 (black) frame coloured, same as the desk frame.


Table top specifications

  • Dimensions : 1800 x 800 mm
  • Core material: 25 mm chipboard, classified E0
  • Surface finish: white melamine, a cable port is supplied as standard.
  • Edges: 2 mm ABS, rounded off

Frame specifications

  • Material/finish: Powdercoated steel RAL 9004 (black)
  • Height adjustment: 620-1270 mm
  • Lifting capacity: 100 kg
  • Operation: The standard user panel features two tactile arrow buttons for height adjustment. The switch-based design prioritizes durability and dependable performance. Thanks to the tactile controls, the panel can be operated by touch alone.
  • Motor : ConSet’s robust and proven 1-motor solution
Table top color:
Frame color:
Table top size:
Table top thickness:
Detailed product information
Download 3D SAT and STEP files (ONLY AVAILABLE AT LOG-IN)
Download high resolution images (ONLY AVAILABLE AT LOG-IN)
Stock and components

A Product can consist of several components. Example, 3 boxes: Top, Legs and cross beam support. Number, decription, Item number, weight, volume and price on the seperate components is listet below.

Item no.:
503-35 4B172 180-80S3 WM
Description:
Sit Stand Desk | 180x80 cm | White with black frame
Stock status
AmountItem no.DescriptionUnit pricePrice
1501-X2 XBXXXLifting column set, Black$ 440,-$ 440,-
1501-XX XB075TFeet and brackets T80, black$ 111,-$ 111,-
1501-XX CB096-166Universal cable-tray, Black$ 67,-$ 67,-
1501-XX HXX2Castorset (4 in black), 501-9, 501-37, XXX-35$ 84,-$ 84,-
1501-XX 4XPOWAPower Box A$ 101,-$ 101,-
1SQ138890Railset, 1720 mm, neutral$ 86,-$ 86,-
1180-80S3 WMSit-Stand Desk Top | 180x80 cm | White$ 230,-$ 230,-

Total
$ 1119,-
Component information
Item no.Length (cm)Width (cm)Height (cm)Weight (kg)EAN
501-X2 XBXXX77191715,005704142162217
501-XX XB075T881169,205704142162262
501-XX CB096-166888153,805704142144817
501-XX HXX2121251,205704142159446
501-XX 4XPOWA221190,705704142133071
SQ138890171534,205704142138892
180-80S3 WM18787426,005704142151112
